Viking Specialized Trailers 18BST
| Manufacturer: Viking Specialized Trailers |
Make & Model
Detailed Specification
55 MPH GVWR 18000 lbs.
27'-3" long
20' (16'-6" flat deck + 3'-6" beavertail) deck length
8' deck width
34-1/2" deck height (unloaded)
4850 lbs. +/- 3%
18000 lb.
W12″ x 16 lbs. per ft., grade 50; Hi-tensile.
2" Nominal Hardwood
6″ I-beam x 3.7 lbs. per ft.
run between main rails on 24″ centers
Dexter multi-point spring with equalizers
(3) 6,000 lb.
Heavy Duty Electric 12″ x 2″ – Each Wheel
8 hole steel disc
(6) 235/80R16, (E) Capacity: 3,000 lbs.
Heavy Duty Jack: 5,000 lb. Screw Type
Black acrylic enamel; rust prohibitive undercoating
2″ nominal oak secured to crossmembers with 5/16″ torque screws; 3/16″ Diamond-plate from main rails to perimeter frame.
12 volt DOT & ICC approved
Description
Tag-A-Long Trailers provide a quick response to growing needs. State, County and City governments favor these trailers for their daily construction and maintenance projects. The ability to couple behind a Dump Truck with Dozer or Back Hoe helps these organizations get on scene quickly, and it gives an immediate response that gets things back up and running.
