Viking Specialized Trailers VFO42102
| Manufacturer: Viking Specialized Trailers |
Make & Model
Detailed Specification
42
42' long x 102' wide
48" Fifth wheel height
56" Deck height
16240 lbs. +/- 3%
100000 lbs.
24” Fabricated main beams, 3/4″ x 6″ top and bottom flange with 3/16” web welded on both sides, 3/8″ web in the neck. All flange and web material is high strength steel.
6″ x 3.7# Jr. I beam on 12″ centers.
2” SAE kingpin, 3/8″ kingpin plate, 24″ kingpin setting (standard).
8″ x 11.5# Structural channel with 1/4” formed stake pockets. 3/8” x 3” Rubrail with double pipe spools.
Watson-Chalin® 50,000 lb. 7 leaf single point spring suspension.
(2) 25,000 Lb., 5” round, 5/8” wall.
16-1/2” x 7”, Type 30/30 brake chambers, outboard drums, Meritor WABCO® (2S/1M) ABS on one axle.
8.25 x 24.5, Steel 10 hole disc, hub piloted (color: white).
11R x 24.5 Radials.
Heavy duty folding schedule 80 pipe, winch retractable.
Shotblasted and painted with a high solid polyurethane paint. Colors: black or red (standard). Optional: epoxy or zinc-rich primer available.
Flush mounted 1-3/8″ Apitong (standard) smooth steel plate located over the tandem areas.
7-Way main receptacle, sealed wiring harness with rubber mounted LED lights. 3 Lights per side including mid-turn.
Inverted fifth wheel,
1″ D-rings,
Sliding winches,
Rear pull loop.
Description
For use in the oil and gas industry, the 42′ float provides quick and easy loading with retractable landing gear and pick-up eye for winch use. The heavy duty 8-5/8″ tailroller assembly handles the heavy loads and is designed with service in mind. The bearings are replaceable and greasable. The 42′ Oilfield Float makes it easy to get around worksites and will hold up to the task. This trailer is built Viking tough! Capacity: 100,000 lbs. GVWR.
